BZ50 Series High Pressure Pump Station Technical Parameters
The oil tank dimensions are reference sizes, and the actual tank dimensions can be customized during manufacturing based on the user's required tonnage capacity.
| Specification | BZ50-6 | BZ50-9 | BZ50-15 | BZ50-24 | BZ50-48 | BZ50-72 | BZ50-96 | BZ50-105 |
| Rated pressure(Mpa) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Theoretical flow rate(L/min) | 6.26 | 8.95 | 16.11 | 24 | 48 | 72 | 96 | 105 |
| Motor Model | Y132S-4 | Y132M-4 | Y160M-4 | Y180M-4 | Y180M-4 | Y180M-5 | Y180M-6 | Y180L-7 |
| Number of motors (units) | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Motor power(Kw) | 5.5 | 5.5 | 7.5 | 11 | 18.5 | 18.5 | 18.5 | 30 |
| Motor speed | 1440 | 1440 | 1460 | 1470 | 1470 | 1470 | 1470 | 1470 |
| Fuel tank size | 长(mm) | 770 | 750 | 800 | 1000 | 1200 | 2000 | 2800 | 2000 |
| 宽(mm) | 550 | 550 | 600 | 700 | 850 | 1200 | 1200 | 1200 |
| 高(mm) | 370 | 490 | 490 | 490 | 600 | 600 | 600 | 600 |
| Oil storage capacity (L) | 125 | 160 | 190 | 270 | 490 | 1150 | 1600 | 1150 |
| Overall Dimension | 长(mm) | 700 | 750 | 800 | 1000 | 1200 | 2000 | 2800 | 2000 |
| 宽(mm) | 550 | 550 | 600 | 700 | 850 | 1200 | 1200 | 1200 |
| 高(mm) | 720 | 930 | 1000 | 1100 | 1100 | 1100 | 1100 | 1100 |
| Weight (Kg) | 280 | 306 | 360 | 470 | 750 | 1100 | 1350 | 1506 |
| Manipulation | manual mode |
| equal-thrust jack | Rated pressure(Mpa) | Flow rate (L/min) | Number of motors | Motor power | operating method |
| BZ32-25 (liter) pumping station | 32 | 25 | 1 | 15 | manually operated |
| BZ32-50(square)泵站 | 32 | 50 | 2 | 15 | manually operated |
| BZ32-40 (liter) pumping station | 32 | 40 | 1 | 22 | manually operated |
| BZ32-80(liter) pumping station | 32 | 80 | 2 | 22 | manually operated |
